| 1) Overall dimension: L600 * W1500 * H1650mm |
| 2) Special sheet metal frame |
| 3) Special multi-layer conveyor belt aluminum alloy turnover box |
| 4) The 120W motor drives the Magazine to step up and down |
| 5) Stepper motor transmission |
| 6) Precision ball screw |
| 8) The maximum PCB size is (L) 480mm * (W) 50-280 |
| 9) Direction: left to right/right to left |
| 10) PCB transfer height: 920± 30mm |
| 11) Multi layer conveyor belt pitch selection is 25, 50 |
| 12) Multilayer W3.5 flat belt transmission |
| 13) The maximum number of storage plates is 20 |
| 14) PLC programmable controller control, with automatic alarm function |
| 15) With buffer storage PCB board and FIFO function |
| 16) The operation control panel is a touch screen |
| 17) Power supply: 220V 50HZ |
| 18) One set of electric box |
