| 1) Overall dimension: L1150 * W1250 * H1200mm |
| 2) Special aluminum profile guide rail and special Qianniao plastic chain |
| 3) 120W brake motor drives ball screw to lift Magazine step by step |
| 6) The specification of turnover box is L355 * W320 * 565mm |
| 7) PCB specification MAX: L350 * W250 |
| 7) Direction: left to right, |
| 8) The lifting platform pitch is selected as 10, 20, 30, 40 |
| 9) Transmission height H=900± twenty |
| 10) Xinjie PLC programmable controller control |
| 11) Automatic loading, unloading and caching |
| 12) The operation control panel is a touch screen |
| 13) Yadeke for pneumatic components (the position of push plate cylinder is adjusted by screw rod) |
| 14) Distinguish good boards from bad boards; |
| 15) You can modify the storage status of each layer in the bin, |
| That is, "NG", "OK" and "None" can be switched mutually; |
| 16) The storage mode can be "straight through" (only on the first floor of the bin) |
| Or "buffer" (each layer can be stored) |
| Or "NG" (alarm when entering a NG board) mode; |
| 17) When the FPC in the storage box is full, there are spare storage boxes that can be replaced with each other |
| 18) The whole box of defective products can be taken out at one time |
| 19) Power supply: 220V 50HZ, air supply: 0.4-0.6MPa |
| 20) Number of fully loaded storage plates: 50PCS |
| 21) One set of electric cabinet. |
