1) Overall dimension: L1500 * W920 * H1200± 30mm

2) Special aluminum profile guide rail and special Qianniao plastic chain

3) The 120W brake motor is driven by a ball screw to raise and lower the Magazine step by step

4) The transmission motor is a Taiwan made 25W constant speed motor,

5) Pneumatic clamp structure

6) The specification of turnover box is (L) 535 * (W) 460 * (H) 565mm

7) PCB specification MAX: (L) 530 * (W) 390mm

8) Direction: right to left/left to right

9) The lifting platform pitch is selected as 10, 20, 30, 40

10) Transmission height H=920± thirty

11) Xinjie PLC programmable controller control

12) With automatic board loading function

13) The operation control panel is a display control true color touch screen;

14) Pneumatic element (the position of push plate cylinder is adjusted by screw rod)

15) Power supply: 220V 50HZ

16) Air source: 0.4-0.6MPa

17) Number of fully loaded storage plates: 50PCS

18) One set of electric cabinet
